The Wabco RKN20632 is a genuine OEM manifold dash valve for heavy-duty truck air systems, also known as part number KN20632 (Haldex) or 9366490170 and 9366490260 (Wabco cross-references). Built to OE specification, this component handles a maximum operating pressure of 150.0 psi across five 3/8" push-to-connect tube ports. The four-point mounting pattern uses M6 x 1 mm fasteners spaced 5.8 x 1.5 in. apart. The assembly measures 394 x 216 x 178 mm and operates through a temperature range of -40°C to +93.3°C. Referenced in WABCO Service Parts Catalog PB19028. Call us to confirm proper fit for your application.
Features
Maximum operating pressure: 150.0 psi
Five 3/8" push-to-connect (P-T-C) tube ports
Four-point mounting: 4x M6 x 1 mm fasteners, hole spacing 5.8 x 1.5 in.
Overall dimensions: 394 x 216 x 178 mm
Operating temperature range: -40°C to +93.3°C
Genuine OEM specification per WABCO Service Parts Catalog PB19028
Tech Specs
- Brand: WABCO
- Part Number: RKN20632
- Cross-References: KN20632 (Haldex), 9366490170 or 9366490260 (Wabco)
- Product Category: Air Systems - Manifold Dash Valve Component
- Technical Specification: OE specification
- Max. Operating Pressure: 150.0 psi
- Port Thread 11: 3/8" Tube Push-to-Connect
- Port Thread 12: 3/8" Tube Push-to-Connect
- Port Thread 21: 3/8" Tube Push-to-Connect
- Port Thread 22: 3/8" Tube Push-to-Connect
- Port Thread 3: 3/8" Tube Push-to-Connect
- Mounting: 4x M6 x 1 mm, hole spacing 5.8 x 1.5 in.
- Size: 394 x 216 x 178 mm
- Temperature Range: -40°C to +93.3°C
- Catalog Reference: PB19028 - WABCO Service Parts Catalog
