The American Mobile Power 3575 (also referenced as A3575) is a 75-gallon steel saddlemount hydraulic reservoir designed for truck-mounted hydraulic systems. Built from steel construction with a saddlemount configuration for secure frame-rail mounting, it features 1-1/2 NPT bottom ports for return and supply line connections. Dimensions run approximately 48 in. high by 48 in. wide by 39 in. long. Also cross-referenced as S-16446 or S16446. Available from Pro Gear and Transmission.
Features
75-gallon steel hydraulic reservoir
Saddlemount design for truck frame-rail installation
1-1/2 NPT bottom ports for supply and return connections
Approximately 48 in. H x 48 in. W x 39 in. L
Cross-references: A3575, S-16446, S16446
Tech Specs
- Capacity: 75 gallons
- Material: Steel
- Mount Type: Saddlemount
- Port Size: 1-1/2 NPT bottom ports
- Height: 48 in.
- Width: 48 in.
- Length: 39 in.
- Cross Reference: A3575, S-16446, S16446
