The Chelsea 442 Series Power Take-Off Assembly, part number 442XWITX-V3XY or 442XWITXV3XY, is a 6-bolt mount PTO built for light-to-medium duty vocational applications including dump trucks, tow trucks, and service trucks. This unit runs a 0.391:1 gear ratio with air shift actuation, a 1-1/4" round standard output shaft, and standard mounting with metric studs. The cast iron housing and tapered cone bearings on the output shaft deliver the torque capacity and service life the 442 Series is known for. Lubrication is splash-type with no pressure lube circuit. The 360-degree rotatable output flange and greaseable output shaft are standard features on this configuration. Call us to confirm proper fit for your application.
Features
Chelsea 442 Series, 6-bolt transmission mount with metric studs
Air shift actuation
0.391:1 gear ratio
1-1/4" round standard output shaft
Cast iron housing with tapered cone bearings on output shaft
Greaseable output shaft and 360-degree rotatable output flange
Tech Specs
- Product Series: 442
- Input Gear Designator: AH
- Gear Ratio: 0.391:1
- Mounting Option: Standard Mount with Metric Studs (6-Bolt)
- Shift Type: Air Shift
- Output Option: 1-1/4" Round Standard Shaft
- Assembly: 3
- Lubricant: No Pressure Lube
