The Dana Spicer 5-1480SPX-MK or 51480SPXMK is a 1480 Series SPX M60 Spicer Extreme universal joint master kit. Both bearing caps measure 1.375 inches in diameter and are the ISR (Inside Snap Ring) style, with cap-to-cap span of 3.010 inches (76.46 mm) on both the A and B spans. Round bearing caps seat inside snap rings, which are included in the kit, as is a grease zerk fitting located at each bearing cap. Steel construction throughout. Cross-references include SJ-733X-733 and YP SJ-733X-733. Call us to confirm proper fit for your specific driveline application before ordering.
Features
1480 SPX M60 Series ISR (Inside Snap Ring) universal joint master kit
1.375 in. diameter round bearing caps, both A and B ends
Cap-to-cap span: 3.010 in. (76.46 mm) on both spans
Greaseable design with grease zerk fitting located at the bearing cap
Snap rings included - no separate hardware purchase required
Steel construction; cross-references SJ-733X-733 and YP SJ-733X-733
Tech Specs
- Part Type: Universal Joint
- OEM Series: SPX 1480 M60
- Bearing Cap Style: ISR (Inside Snap Ring), both ends
- Bearing Cap Type: Round
- Bearing Cap Diameter A: 1.375 in.
- Bearing Cap Diameter B: 1.375 in.
- Cap-to-Cap Span A (OSR): 3.010 in. (76.46 mm)
- Cap-to-Cap Span B (OSR): 3.010 in. (76.46 mm)
- Snap Ring Type: Inside
- Snap Rings Included: Yes
- Greaseable: Yes
- Grease Zerk Location: Bearing Cap
- Grease Zerk Included: Yes
- Material: Steel
- VMRS Code: 024002046
- Cross Reference: SJ-733X-733, YP SJ-733X-733
