The Dana Spicer 211793-1X or 2117931X is a Series 1350, Style 15 drive shaft center support bearing assembly. The bearing bore (dimension A) measures 1.574 in., centerline to mounting (dimension B) is 2.250 in., bracket width (dimension C) is 1.500 in., and centerline to centerline (dimension D) is 6.620 in. Bolt hole diameter is 0.560 in. These dimensions make it straightforward to verify fitment against your existing driveline before ordering. Sold by Pro Gear and Transmission as a genuine Dana Spicer part. Call us to confirm proper fit for your specific application.
Features
Dana Spicer part number 211793-1X or 2117931X
Series 1350, Style 15 center bearing assembly
Bearing bore (A): 1.574 in.
Centerline to mounting (B): 2.250 in.
Bracket width (C): 1.500 in.
Centerline to centerline (D): 6.620 in., bolt hole: 0.560 in.
Tech Specs
- Series: 1350
- Style: 15
- Type: Drive Shaft Center Support Bearing Assembly
- Bearing Bore - Dim. A (in): 1.574
- Centerline to Mounting - Dim. B (in): 2.250
- Bracket Width - Dim. C (in): 1.500
- Centerline to Centerline - Dim. D (in): 6.620
- Bolt Hole Diameter (in): 0.560
