The Dana Spicer 3-4-13061-1X or 34130611X is a 1480 series end yoke assembly built for heavy-duty driveline applications. It features a splined hole bore with 39 involute splines and a major diameter of 2.024 in., accepting a hub diameter of 2.625 in. The BS yoke style measures 4.344 in. from centerline to end hub, with a 2.250 in. length through the hole and a 0.250 in. counterbore depth. Constructed from steel, this end yoke is a genuine Dana Spicer part sold by Pro Gear and Transmission. Call us to confirm proper fit for your specific driveline configuration.
Features
1480 series end yoke assembly
39-spline involute splined hole bore
Major diameter: 2.024 in.; hub diameter: 2.625 in.
Centerline to end hub: 4.344 in.; length through hole: 2.250 in.
Counterbore depth: 0.250 in.
BS yoke style, steel construction
Tech Specs
- Series: 1480
- Yoke Style: BS
- Spline Count: 39
- Involute Spline: Yes
- Type: Splined Hole
- Major Diameter: 2.024 in.
- Hub Diameter (R): 2.625 in.
- C/L To End Hub (S): 4.344 in.
- Length Thru Hole (Q): 2.250 in.
- C-Bore Depth: 0.250 in.
- Material: Steel
- VMRS: 022003072
