Dana Spicer part 6.3-4-05582-1 or 634055821 is a 1760 series HR-style pinion shaft end yoke with a splined hole. It carries 49 involute splines on a 2.544 in. major diameter hub. The bearing cap dimension (D) is 1.938 in., the outside yoke dimension (E) is 7.094 in., and the centerline-to-end-hub length (S) measures 5.750 in. The hub bore diameter is 3.819 in. with a counterbore 2.64 in. in diameter and 0.240 in. deep, and the length through hole (Q) is 2.677 in. This yoke accommodates a maximum joint angle of 29.5 degrees and includes a slinger/plug. Constructed of steel. Call us to confirm proper fit for your application.
Features
1760 series driveline end yoke, HR yoke style
49-count involute spline, 2.544 in. major diameter
Bearing cap dimension (D): 1.938 in.
Outside yoke dimension (E): 7.094 in.; centerline to end hub (S): 5.750 in.
Hub bore diameter: 3.819 in.; length through hole (Q): 2.677 in.
Includes slinger/plug; steel construction; maximum joint angle 29.5 degrees
Tech Specs
- Series: 1760
- Yoke Style: HR
- Type: Splined Hole
- Spline Count: 49
- Involute Spline: Yes
- Major Diameter: 2.544 in.
- Hub Diameter (R): 3.819 in.
- Bearing Cap Dimension (D): 1.938 in.
- Outside Yoke Dimension (E): 7.094 in.
- Centerline to End Hub (S): 5.750 in.
- Length Thru Hole (Q): 2.677 in.
- C-Bore Diameter: 2.64 in.
- C-Bore Depth: 0.240 in.
- Joint Angle #1: 29.5 degrees
- Includes Slinger/Plug: Yes
- Assembly: No
- Material: Steel
- VMRS: 022003072
