Genuine Dana Spicer Svl Rear Axle for light axle application P/N: 2023686-4 or 20236864, Genuine parts, direct from Dana Spicer. Hassle-free returns and top-notch quality! Authentic Genuine Dana Spicer parts shipped worldwide. Expert assistance available!
Tech Specs
- Axle Model FORD 8.8
- Material Steel
- Invoice SVL REAR AXLE SHAFT
- Axle Cover Bolt Hole Qty 10
- ABS/Non-ABS Non-ABS
- Location LH
- Axle Length (In) 32.244
- Length (IN) 32.244
- Spline Count 28 Inboard
- Axle Spline Count 28 Inboard
- Bolt Pattern 5 X 4.50
- Wheel Stud Hole Diameter (In) 0.600
- Brake Pilot Diameter (In) 2.774
- Cover Bolt Quantity 10
- Bearing Pilot Diameter (In) 1.400
- Includes Tone N
- Axle Length (Mm) 818.997
- ABS Sensor Ring Included No
- ABS Sensor Ring Installed N
- Axle Shaft Included Y
- Axle Type Complete Assembly
- Bearing Included N
- Full-Floating Or Semi-Floating Semi-Floating
- Inner Axle Included Y
- Number Of Wheel Lugs 5
- Outer Axle Included Y
- Quantity 1
- Retainer Ring Included N
- Seal Included N
- Seal Kit Included N
- U-Joint Included N
- Wheel Bearing Included N
- Wheel Bolt Prep Kit Included N
- Wheel Nuts Included N
- Wheel Studs Included Y
- Length (MM) 818.997
