The Dana Spicer 6-82-1351-7 (also listed as 68213517) is a 1710 series yoke shaft built to BP style with a 45-degree angle. It carries a 16-spline profile with a major spline diameter of 2.500 inches, a minor spline hole diameter of 2.125 inches, and a spline width of 0.234 inches. Spline length measures 3.500 inches, centerline to end of spline (dimension K) is 11.660 inches, and end-spline to point/radius (dimension R) is 8.656 inches. Sold by Pro Gear and Transmission as a genuine Dana Spicer component. Call us to confirm proper fit for your application before ordering.
Features
Dana Spicer 1710 series yoke shaft, part number 6-82-1351-7 or 68213517
BP style, 45-degree angle
16-spline profile, 2.500 in. major spline diameter, 2.125 in. minor spline hole diameter
Spline width 0.234 in., spline length 3.500 in.
Centerline to end of spline (K): 11.660 in.
End-spline to point/radius (R): 8.656 in.
Tech Specs
- Series: 1710
- Style: BP
- Angle: 45.0 degrees
- Spline Count: 16
- Major Spline Diameter: 2.500 in.
- Spline Hole Minor Diameter: 2.125 in.
- Spline Width: 0.234 in.
- Spline Length (L): 3.500 in.
- Centerline to End of Spline (K): 11.660 in.
- End/Spline to Point/Radius (R): 8.656 in.
- VMRS: 024002061
