The Midland Haldex 19840 is a saddle-mounted single-compartment air reservoir designed for heavy-duty truck brake systems. It measures 9-1/2 inches in diameter with 27-1/2-inch mounting centers and delivers 1490 cubic inches of volume. Two 3/4-inch valve mounting ports are reinforced for added strength, and mounting flanges are positioned above the center line. Working pressure is certified to 150 PSI, and the reservoir conforms to SAE J10B specifications. Internal and external corrosion protection is tested to withstand a 500-hour salt spray cycle. In ABS-equipped vehicles, use of isolator pads is recommended. Call us to confirm proper fit for your application.
Features
Saddle-mounted single-compartment design with 27-1/2" mounting centers
9-1/2" diameter, 1490 cu. in. volume
Certified to 150 PSI working pressure
Two 3/4" valve mounting ports, reinforced for extra strength
Mounting flanges positioned above center line
Conforms to SAE J10B specifications; internal and external corrosion protection rated to 500-hour salt spray test
Tech Specs
- Mounting Centers: 27-1/2"
- Diameter: 9-1/2"
- Volume: 1490 cu. in.
- Valve Mounting Ports: (2) 3/4"
- Mounting Flanges: Above Center Line
- Working Pressure: 150 PSI (certified)
- Compliance: SAE J10B
