The Muncie 14TA3997 is a Flange/Seal Assembly designed for "Q", "R", and "T" output configurations on Muncie power take-offs, including the FA6B and CS series. The assembly includes two components: hydraulic flange 14T39141 and output shaft seal 11T37790. The "Q" output uses an SAE "A" 2-bolt flange with an SAE "B" 7/8"-13T splined shaft; the "R" output uses an SAE "A" 2-bolt flange with an SAE "A" 5/8"-9T splined shaft; the "T" output uses an SAE "A" 2-bolt flange with an SAE "A" 3/4"-11T splined shaft. Also referenced as part of the FR63 flange/seal group in Muncie service documents. Call us to confirm proper fit for your application.
Features
Covers "Q", "R", and "T" PTO output shaft configurations
Includes hydraulic flange (14T39141) and output shaft seal (11T37790)
"Q" output: SAE "A" 2-bolt flange, SAE "B" 7/8"-13T splined shaft
"R" output: SAE "A" 2-bolt flange, SAE "A" 5/8"-9T splined shaft
"T" output: SAE "A" 2-bolt flange, SAE "A" 3/4"-11T splined shaft
Referenced in Muncie FA6B and CS series service parts documents
Tech Specs
- Output Configurations Covered: Q, R, and T
- Q Output Shaft: SAE "A" 2-bolt flange, SAE "B" 7/8"-13T splined shaft
- R Output Shaft: SAE "A" 2-bolt flange, SAE "A" 5/8"-9T splined shaft
- T Output Shaft: SAE "A" 2-bolt flange, SAE "A" 3/4"-11T splined shaft
- Kit Includes: Hydraulic Flange 14T39141, Output Shaft Seal 11T37790
- Applicable Series: Muncie FA6B, CS24, CS25 (FR63 flange/seal group)
