The Wabco Hand Brake Valve, part number 961-722-184-0 or 9617221840, is a genuine OEM air system hand control valve built to OE specification. It operates at a maximum pressure of 145.04 psi and features a 73° actuation angle for precise driver control. The valve mounts via two M8 fasteners with a 3.15 in. hole spacing, and both port threads are M14 x 1.5. The 8.5 mm exhaust hose nozzle suits standard air system routing. The unit measures 210 x 118 x 104 mm and is rated for a temperature range of -40°C to +80°C, making it suitable for demanding operating environments. Sold by Pro Gear and Transmission. Call us to confirm proper fit for your application.
Features
Genuine OEM specification - matches original Wabco factory build
Max operating pressure: 145.04 psi
Actuation angle: 73°
Port threads: M14 x 1.5 (both ports)
Mounting: 2x M8 fasteners, 3.15 in. center-to-center hole spacing
Temperature rated: -40°C to +80°C
Tech Specs
- Actuation Angle: 73°
- Max Operating Pressure: 145.04 psi
- Port Thread 1: M14 x 1.5
- Port Thread 2: M14 x 1.5
- Exhaust Hose Nozzle Diameter: 8.5 mm
- Mounting: 2x M8, hole spacing 3.15 in.
- Dimensions: 210 mm x 118 mm x 104 mm
- Temperature Range: -40°C to +80°C
- Color: Black
- Technical Specification: OE specification
