This horn relay fits Mack and Navistar cab electrical circuits and is made by PAI as a replacement switch. Rated 20/40 Amp for 12 Vdc systems, it uses a 5-pin connector and measures 2.65 in. long by 1.66 in. wide by 1.40 in. high, with a 0.250 in. mounting hole. It switches high current to the horn circuit when triggered by the horn button or steering wheel switch, keeping that low-current switch protected from load damage.
Features
20/40 Amp rating
12 Vdc operation
5-pin connector
2.65 in. overall length x 1.66 in. width x 1.40 in. height
0.250 in. mounting hole I.D.
Cross-reference: Mack 4333-1688314C1, Navistar 1688314, 1688314C1
Tech Specs
- Amperage: 20/40 Amp
- Voltage: 12 Vdc
- Connector: 5-Pin
- Overall Length: 2.65 in.
- Width: 1.66 in.
- Height: 1.40 in.
- Hole I.D.: 0.250 in.
- Cross Reference: Mack 4333-1688314C1, Navistar 1688314, 1688314C1
