Meritor part 09-002229 or 09002229 is a Grade 10.9, M22 x 1.5-6g right-hand threaded wheel stud sold in a 4-pack. The headed, serrated stud features a round head 1.31 in. in diameter and 0.31 in. thick. Body diameter measures 0.890 in. with a body length of 0.87 in. The serrated shank section spans 0.38 in. at a serration diameter of 0.939 in., locking the stud securely into the hub or drum. Thread length runs 3.84 in. with an overall length from under the head of 4-7/8 in. VMRS code 018-003-009. Also referenced as 823509002229 and TDA09002229. Call us to confirm proper fit for your application.
Non returnable item
This unit is sold in packs of 4.
Features
Metric thread: M22 x 1.5-6g, right-hand direction
Grade 10.9 headed stud with round head style
Head diameter 1.31 in., head thickness 0.31 in.
Serrated shank: 0.939 in. serration diameter, 0.38 in. serration length
Thread length 3.84 in.; length from under head 4-7/8 in.
Sold as a 4-pack; also referenced as 823509002229 and TDA09002229
Tech Specs
- Thread: M22 x 1.5-6g
- Thread Direction: Right-Hand (RH)
- Thread Diameter: 22.0 mm
- Threads per mm: 1.5
- Thread Length: 3.84 in.
- Length from Under Head: 4-7/8 in.
- Body Diameter: 0.890 in.
- Body Length: 0.87 in.
- Serration Diameter: 0.939 in.
- Serration Length: 0.38 in.
- Head Style: Round
- Head Diameter: 1.31 in.
- Head Thickness: 0.31 in.
- Grade: 10.9
- Type: Headed
- Hub/Drum End Length: 0.87 in.
- VMRS Code: 018-003-009
- Unit Pack: 4
