Meritor wheel stud E10259-R or E10259R is a right-hand thread wheel end stud sold here in a 5 pack. It uses a clipped D-head design and is built to Grade 8 strength for Dura-Light hub applications. The thread is 3/4"-16 UNF-3A with a plain (unserrated) shank, a 0.75 in. thread diameter, and 16 threads per inch. Body diameter measures 0.888 in. with a 0.63 in. body length, and overall length from under the head is 2 11/32 in. with a 1.38 in. thread length and a 0.31 in. head thickness. Call us to confirm proper fit for your hub.
Interchanges:
- Automann 2016260R
- BWP M3960
- Dayton Parts Batco 131501R
This unit is sold in packs of 5.
Features
Right-hand 3/4"-16 UNF-3A thread, 16 threads per inch
Grade 8 strength, clipped D-head style
Plain (unserrated) shank, headed type
Body diameter 0.888 in., body length 0.63 in.
Length under head 2 11/32 in., thread length 1.38 in.
For Dura-Light hubs; sold as a 5 pack (E10259-R or E10259R)
Tech Specs
- Head Style:Clipped - D Head
- Metric Thread Size:3/4-16 UNF-3A
- Body Length:0.63 in.
- Grade:8
- Body Diameter:0.888 in.
- Length from Under Head:2 11/32 in.
- Thread:3/4"-16
- Serration:Plain
- Type:Headed
- Thread Direction:RH
- Head Thickness:0.31 in.
- Application:For Dura-Light Hubs
- Thread Length:1.38 in.
- Threads per Inch:16
- OEM:Walther EMC 02-00027
- Thread Diameter:0.75 in.
