The Meritor E-9009 or E9009 is a headed wheel stud from Euclid's Wheel End Hardware line, sold in a 5-pack. It carries a Grade 10.9 rating and uses an M22 x 1.5 thread with a total length from under the head of 2-9/16 in. The body diameter measures 0.975 in. and the body length is 0.72 in., with 1.69 in. of thread length. The serrated shank has a serration length of 0.38 in. for secure press-fit retention in the wheel end. The round head style is active production. Call us to confirm proper fit for your application.
Interchanges:
- Automann 2016246
- BWP M3671
- Dayton Parts Batco 131573
- Navistar 1660579C1
- Trailmobile 36101166
- World Truck 1681047
This unit is sold in packs of 5.
Features
Euclid Wheel End Hardware, Wheel Stud (Part E-9009 or E9009)
Grade 10.9 strength rating
M22 x 1.5 thread; thread length 1.69 in.
2-9/16 in. length from under head; body diameter 0.975 in.
Serrated shank with 0.38 in. serration length for secure press-fit retention
Tech Specs
- Part Number: E-9009 or E9009
- Brand: Euclid (Meritor)
- Type: Headed Wheel Stud
- Grade: 10.9
- Thread: M22 x 1.5
- Length from Under Head: 2-9/16 in.
- Body Diameter: 0.975 in.
- Body Length: 0.72 in.
- Thread Length: 1.69 in.
- Head Style: Round
- Serration: Serrated
- Serration Length: 0.38 in.
- Unit Pack: 5
- VMRS Code: 018-003-009
- Status: Active
