Bendix 065154 proportioning valve, listed as the LQ-5 type, for air brake systems. A ratio valve of this kind limits the air pressure sent to the steering axle brakes during normal tractor-trailer braking, so the front brakes are not overworked while a trailer is hooked up. Inside, a stepped proportioning piston sets how much pressure is cut, and a second spring-loaded piston lets delivery pressure blend back up to full strength during hard brake applications. Listed dimensions are 4.35 x 2.36 x 2.76 in. (height x width x length). A genuine Bendix part from Pro Gear and Transmission. Call us to confirm proper fit for your application.
A factory handling fee of $20.00 per unit is added at checkout.
Features
Bendix part number 065154, proportioning valve LQ-5
Limits steering axle brake pressure during normal tractor-trailer braking
Stepped proportioning piston sets the pressure reduction
Blend back piston returns delivery to full pressure on hard brake applications
Listed dimensions 4.35 x 2.36 x 2.76 in. (height x width x length)
A genuine Bendix part sold by Pro Gear and Transmission
Tech Specs
- Brand: Bendix
- Part number: 065154
- Type: Proportioning valve LQ-5
- Height: 4.35 in.
- Width: 2.36 in.
- Length: 2.76 in.
