The Chelsea 442 Series Power Take-Off, part number 442XRAHX-V3GB or 442XRAHXV3GB, is a 6-bolt transmission mount PTO built around a cast iron housing and tapered cone bearings on the output shaft. This unit runs a 0.391:1 gear ratio with air shift actuation and mounts via the standard configuration with metric studs. The 1-1/4" round output shaft operates without a pressurized lubrication system, keeping the installation straightforward. Output flanges are rotatable for clearance flexibility, and the output shaft is greaseable for long service life. Suited to tow trucks, dump trucks, and service truck applications. Call us to confirm proper fit for your transmission.
Features
Chelsea 442 Series, 6-bolt transmission mount with metric studs
Air shift actuation
0.391:1 gear ratio
1-1/4" round standard output shaft, no pressure lube system
Cast iron housing with tapered cone bearings on the output shaft
Rotatable output flanges and greaseable output shaft
Tech Specs
- Product Series: 442
- Input Gear Designator: AH
- Gear Ratio: 0.391:1
- Mounting Option: Standard Mount with Metric Studs
- Shift Type: Air Shift
- Output Option: 1-1/4" Round Standard Shaft
- Assembly: 3
- Lubricant: No Pressure Lube
