Chelsea PTO Assembly P/N: 281GGFJP-E8RK or 281GGFJPE8RK

281GGFJP-E8RK Chelsea PTO Assembly

Chelsea

Listing Price: $3,953.74
Sale Price: $2,894.13

This item qualifies for FREE shipping on orders over $295 and under 70 lbs

(No reviews yet) Write a Review
Product Code:
CHL281GGFJPE8RK
Condition:
New
Availability:
Usually Ships in 3 to 5 Business Days
Adding to cart… The item has been added
The Chelsea 281GGFJP-E8RK or 281GGFJPE8RK is a hydraulically shifted (PowerShift) Power Take-Off from the Chelsea 281 Series, designed for automatic transmissions with a 10-bolt aperture including Allison and Caterpillar units. It carries a single, continuous duty torque rating and is available with pressure lube or wet spline lubrication. The ductile iron bearing cap is 117% stronger than gray iron, and the clutch pack uses steel discs 80% thicker than the previous generation to resist premature tooth wear. Nine speed ratios cover both low- and high-speed applications. This part crosses to 280GGFJP-E8RK or 280GGFJPE8RK. Call us to confirm proper fit for your specific transmission and application.

Features

Hydraulic PowerShift operation for hot-shift engagement on automatic transmissions
Ductile iron bearing cap rated 117% stronger than gray iron predecessor
Clutch pack steel discs 80% thicker than 280 Series for reduced tooth wear
O-ring sealing configuration between housing and bearing cap improves clamp load and reduces vibrational effects
Nine speed ratios including dedicated low- and high-speed options
Wet spline lubrication option extends shaft life 7 to 10 times versus standard
SmartStart feature reduces shock load at start-up; Electronic Overspeed Control (EOC) protects driven equipment
Rotatable cast-iron flanges reduce interference clearance issues; positive stop for driveline outputs eliminates oil seal damage

Tech Specs

  • Mounting Type: 10-Bolt aperture
  • Shift Type: PowerShift (Hydraulic)
  • Continuous Operation: Yes
  • Compatible Transmissions: Allison and Caterpillar automatic transmissions
  • Output Types: SAE B pump flange, SAE C pump flange, ISO 7652 pump flange, driveline
  • Lubricant Options: Pressure lube (P) or wet spline (W)
  • Speed Ratios: Nine, including low and high speeds
  • Cross Reference: 280GGFJP-E8RK or 280GGFJPE8RK

Additional Information

Chelsea PTO 281 Series model break down

Parts Manual: Chelsea 281 Series PTO Parts Manual (PDF) — exploded views, item numbers and the full parts breakdown for this series.

!
