The Chelsea 442 Series Power Take-Off Assembly, part number 442GRJHX-P4XK or 442GRJHXP4XK, is a 6-bolt mount PTO built around a cast iron housing with tapered cone bearings on the output shaft. This unit runs a 0.391:1 gear ratio and is activated by air shift. The output is a 1-1/4" round standard shaft, and the mounting configuration uses standard mount with metric studs. Lubrication is splash-type with no pressure lube circuit. The 442 Series fits a wide range of light-to-medium duty vocational applications including dump trucks, service trucks, and tow trucks. Call us to confirm proper fit for your transmission.
Features
Chelsea 442 Series, 6-bolt transmission mounting with metric studs
Air shift activation
0.391:1 gear ratio
1-1/4" round standard output shaft
Cast iron housing with tapered cone bearings for long service life
Rotatable output flange and greaseable output shaft
Tech Specs
- Product Series: 442
- Input Gear Designator: AH
- Gear Ratio: 0.391:1
- Mounting Option: Standard Mount with Metric Studs (6-Bolt)
- Shift Type: Air Shift
- Output Option: 1-1/4" Round Standard Shaft
- Assembly: 3
- Lubricant: No Pressure Lube
