The Chelsea 442 Series Power Take-Off Assembly, part number 442KWBQX-W6XD or 442KWBQXW6XD, is a 6-bolt, standard-mount PTO configured with a cable shift mechanism. The output is a 1-1/4" round standard shaft, and the unit runs without pressure lubrication. Built on a cast iron housing with tapered cone bearings on the output shaft, the 442 Series is suited for light-to-medium duty vocational applications including tow trucks, dump trucks, service trucks, and small aerial trucks. The series covers a broad range of output options and speed ratios, making it adaptable across many 6-bolt transmission applications. Call us to confirm proper fit for your application.
Features
Chelsea 442 Series, 6-bolt standard mount
Cable shift configuration
1-1/4" round standard output shaft (no pressure lube)
Cast iron housing with tapered cone bearings for long service life
Tech Specs
- Product Series: 442
- Mounting Option: Standard Mount without Stud Kit (K)
- Gear Ratio Code: W (26/17)
- Input Gear Designator: BQ
- Lube Option: No Pressure Lube (X)
- Shift Option: Cable (Wire) Shift (W)
- Assembly Arrangement: 6
- Output Option: 1-1/4" Round Standard Shaft with 5/16" Key (XD)
