The Chelsea 442 Series Power Take-Off, part number 442XSAXX-A6XD or 442XSAXXA6XD, is a 6-bolt mount PTO built around air shift actuation and a 0.391:1 gear ratio. The output is a 1-1/4" round standard shaft, and the unit mounts via standard configuration with metric studs. No pressure lube is required. The cast iron housing pairs with tapered cone bearings on the output shaft to handle the torque demands of light-to-medium duty vocational work -- tow trucks, dump trucks, service trucks, and small aerial units are typical applications. The 442 Series supports thirty-six output options and eleven internal speed ratios across the family, making it a widely adaptable platform. Call us to confirm proper fit for your application.
Features
Chelsea 442 Series, 6-bolt mounting with metric studs
Air shift actuation
0.391:1 gear ratio
1-1/4" round standard output shaft
Cast iron housing with tapered cone bearings on output shaft
No pressure lube required; greaseable output shaft
Tech Specs
- Product Series: 442
- Input Gear Designator: AH
- Gear Ratio: 0.391:1
- Mounting Option: Standard Mount with Metric Studs (6-Bolt)
- Shift Type: Air Shift
- Output Option: 1-1/4" Round Standard Shaft
- Assembly: 3
- Lubricant: No Pressure Lube
