The Chelsea 442 Series Power Take-Off (PTO), part number 442XSAXX-A6XK or 442XSAXXA6XK, is a 6-bolt mounted unit built for light-to-medium duty vocational truck applications. This configuration runs a 0.391:1 gear ratio with air shift actuation, a 1-1/4" round standard output shaft, and standard mounting with metric studs. The cast iron housing and tapered cone bearings on the output shaft are characteristic of the 442 Series, giving it a strong torque rating and extended service life. The no-pressure-lube design simplifies maintenance, and the greaseable output shaft keeps the unit running between service intervals. Common applications for the 442 Series include dump trucks, tow trucks, service trucks, and aerial units. Call us to confirm proper fit for your transmission.
Features
442 Series, 6-bolt transmission mount with metric studs
Gear ratio: 0.391:1
Shift type: Air shift
Output: 1-1/4" round standard shaft
No-pressure-lube configuration
Cast iron housing with tapered cone bearings on the output shaft
Tech Specs
- Product Series: 442
- Input Gear Designator: AH
- Gear Ratio: 0.391:1
- Mounting Option: Standard Mount with Metric Studs (6-Bolt)
- Shift Type: Air Shift
- Output Option: 1-1/4" Round Standard Shaft
- Assembly: 3
- Lubricant: No Pressure Lube
