The Chelsea 442 Series Power Take-Off, part number 442XSESX-A5XR or 442XSESXA5XR, is a 6-bolt mount PTO built for light-to-medium duty vocational applications including dump trucks, tow trucks, and service trucks. This unit runs a 0.391:1 gear ratio with air shift actuation and a 1-1/4" round standard output shaft. Mounting is standard with metric studs. The cast iron housing and tapered cone bearings on the output shaft contribute to the 442 Series' class-leading torque capacity and long service life. No pressure lube configuration (X) keeps the design straightforward. Call us to confirm proper fit for your transmission before ordering.
Features
Chelsea 442 Series, 6-bolt transmission mount with metric studs
Air shift actuation (no cable or mechanical linkage required)
0.391:1 gear ratio
1-1/4" round standard output shaft, greaseable for extended service life
Cast iron housing with tapered cone bearings on the output shaft
Low-profile shift cover with 360-degree rotatable output flange option for clearance flexibility
Tech Specs
- Product Series: 442
- Input Gear Designator: AH
- Gear Ratio: 0.391:1
- Mounting Option: Standard Mount with Metric Studs
- Shift Type: Air Shift
- Output Option: 1-1/4" Round Standard Shaft
- Assembly: 3
- Lubricant: No Pressure Lube
