The Chelsea 442 Series Power Take-Off, part number 442XSESX-S5XK or 442XSESXS5XK, is a 6-bolt mounting PTO built around a cast iron housing with tapered cone bearings on the output shaft. This assembly runs an air shift mechanism and an SAE B 2 or 4-bolt flange with a 7/8" 13-tooth SAE B shaft. Mounting uses a standard mount. The unit carries no pressure lube requirement. The 442 Series is suited for tow trucks, dump trucks, service trucks, and aerial applications. Call us to confirm proper fit for your specific transmission before ordering.
Features
Chelsea 442 Series, 6-bolt standard mount
Air shift mechanism
SAE B 2 or 4-bolt flange with a 7/8" 13-tooth SAE B shaft, no pressure lube required
Cast iron housing with tapered cone bearings for long service life
Tech Specs
- Product Series: 442
- Mounting Type: 6-Bolt
- Mounting Option: Standard Mount (X)
- Gear Ratio Code: S (24/22)
- Input Gear Designator: ES
- Lube Option: No Pressure Lube (X)
- Shift Option: Air Shift with PTO/Dump Pump Combo Valve (with Kick-Out, with Neutral Spring Return) (S)
- Assembly Arrangement: 5
- Output Option: SAE B 2 or 4-Bolt Flange, SAE B Shaft (7/8" 13T) (XK)
