The Chelsea 442 Series Power Take-Off Assembly, part number 442XUEDX-W3XD or 442XUEDXW3XD, is a 6-bolt mounting PTO built for light-to-medium duty vocational applications including dump trucks, service trucks, tow trucks, and aerial units. This unit runs an air shift mechanism, a 0.391:1 gear ratio, and a 1-1/4" round standard output shaft. Mounting uses a standard configuration with metric studs. The cast iron housing and tapered cone output shaft bearings are characteristic of the 442 Series, designed to handle intermittent torque in the 201-300 lb-ft range. No pressure lube is required for this configuration. Call us to confirm proper fit for your transmission and application.
Features
Air shift operation
0.391:1 gear ratio
1-1/4" round standard output shaft
Standard 6-bolt mount with metric studs
No pressure lube configuration
Cast iron housing with tapered cone output shaft bearings
Tech Specs
- Product Series: 442
- Input Gear Designator: AH
- Gear Ratio: 0.391:1
- Mounting Option: Standard Mount with Metric Studs
- Shift Type: Air Shift
- Output Option: 1-1/4" Round Standard Shaft
- Assembly: 3
- Lubricant: No Pressure Lube
- Mounting Bolt Pattern: 6-Bolt
