The Chelsea 442 Series Power Take-Off Assembly, part number 442XUESX-W3RA or 442XUESXW3RA, is a 6-bolt mount PTO built for light-to-medium duty vocational applications including dump trucks, tow trucks, and service trucks. This unit uses cable shift actuation, a rotatable SAE B 2-bolt flange with a 7/8" 13-tooth SAE B shaft, and standard mounting. The cast iron housing and tapered cone bearings on the output shaft are characteristic of the 442 Series design, delivering a reliable torque rating and extended service life. No pressure lube is required. Call us to confirm proper fit for your transmission and application.
Features
Chelsea 442 Series, 6-bolt transmission mount
Shift type: Cable Shift
Output: rotatable SAE B 2-bolt flange with a 7/8" 13-tooth SAE B shaft
No pressure lube required
Cast iron housing with tapered cone output shaft bearings for extended service life
Rotatable output flanges for improved installation clearance
Tech Specs
- Product Series: 442
- Mounting Option: Standard Mount (X)
- Gear Ratio Code: U (26/20)
- Input Gear Designator: ES
- Lube Option: No Pressure Lube (X)
- Shift Option: Cable (Wire) Shift (W)
- Assembly Arrangement: 3
- Output Option: Rotatable SAE B 2-Bolt Flange, SAE B Shaft (7/8" 13T) (RA)
