The Chelsea 442 Series Power Take-Off, part number 442XXAXX-A6XE or 442XXAXXA6XE, is a 6-bolt transmission-mount PTO built around an air shift mechanism and a 0.391:1 gear ratio. The output is a 1-1/4" round standard shaft, and the unit mounts via standard mount with metric studs. Internally, it runs with no pressure lube. The 442 Series uses a cast iron housing and tapered cone bearings on the output shaft, making it a proven choice for tow trucks, service trucks, dump trucks, and aerial work trucks. Call us to confirm proper fit for your transmission before ordering.
Features
Chelsea 442 Series, 6-bolt transmission mount with metric studs
Air shift operation
0.391:1 gear ratio
1-1/4" round standard output shaft, no pressure lube required
Cast iron housing with tapered cone bearings on output shaft
Rotatable output flanges and greaseable output shafts for extended service life
Tech Specs
- Product Series: 442
- Input Gear Designator: AH
- Gear Ratio: 0.391:1
- Mounting Option: Standard Mount with Metric Studs (6-Bolt)
- Shift Type: Air Shift
- Output Option: 1-1/4" Round Standard Shaft
- Assembly: 3
- Lubricant: No Pressure Lube
