The Chelsea 442 Series Power Take-Off 442ZUEDX-W3XD or 442ZUEDXW3XD is a 6-bolt mount PTO built for light-to-medium duty vocational applications including dump trucks, tow trucks, and service trucks. This unit runs a 0.391:1 gear ratio with air shift actuation and delivers power through a 1-1/4" round standard output shaft. Mounting uses the standard configuration with metric studs. The no-pressure-lube design is paired with greaseable output shafts to simplify field maintenance. Cast iron housing and tapered cone bearings on the output shaft give the 442 Series its class-leading torque rating and extended service life. Call us to confirm proper fit for your transmission application.
Features
Chelsea 442 Series, 6-bolt standard mount with metric studs
Gear ratio: 0.391:1
Shift type: Air shift
Output: 1-1/4" round standard shaft
Cast iron housing with tapered cone bearings on the output shaft
Greaseable output shafts; no-pressure-lube design
Tech Specs
- Input Gear Designator: AH
- Gear Ratio: 0.391:1
- Mounting Option: Standard Mount with Metric Studs
- Shift Type: Air Shift
- Output Option: 1-1/4" Round Standard Shaft
- Assembly: 3
- Lubricant: No Pressure Lube
- Product Series: 442
- Mounting: 6-Bolt
