The Chelsea 880XRAHX-V3XV or 880XRAHXV3XV is a two-gear power take-off assembly built for demanding intermittent-duty applications. It mounts via an 8-bolt pattern and uses lever mechanical shift for straightforward, reliable engagement. The output shaft is a 1-1/2"-10 spline with a 1410 companion flange, and the dual-pump design allows a hydraulic pump to be mounted on each end of the PTO simultaneously. Shaft power output reaches 48 HP at 500 RPM and 95 HP at 1,000 RPM, with intermittent torque capacity up to 500 lb-ft (678 Nm). The cast iron housing provides long service life, and the simple backlash adjustment reduces installation time. Compatible transmissions include Volvo/Mack, Allison, and Eaton/Fuller platforms. Call us to confirm proper fit for your specific transmission and application.
Features
8-bolt mounting pattern for broad transmission compatibility including Volvo/Mack, Allison, and Eaton/Fuller
Lever mechanical shift for direct, positive PTO engagement
1-1/2"-10 spline output shaft with 1410 companion flange
Dual-pump output allows simultaneous pump mounting on each end of the unit
Shaft power output: 48 HP at 500 RPM, 95 HP at 1,000 RPM
Intermittent torque rating up to 500 lb-ft (678 Nm); cast iron housing for extended service life
Tech Specs
- INTERMITTENT TORQUE: 500 lb-ft / 678 Nm (check application pages for actual torque ratings)
- TRANSMISSION COMPATIBILITY: Volvo/Mack, Allison, Eaton/Fuller
- SHIFT TYPE: Lever Mechanical
- OUTPUT SHAFT TYPE: 1-1/2" - 10-tooth spline with 1410 companion flange
- MOUNTING TYPE: 8-bolt
- OUTPUT POWER: 56+ HP / 51+ kW
- SHAFT POWER: 48 HP (36 kW) at 500 RPM; 95 HP (71 kW) at 1,000 RPM
- GEAR COUNT: 2-gear assembly
