The Chelsea 885 Series Power Take-Off, part number 885XJAKP-A6XS or 885XJAKPA6XS, is a hydraulic PowerShift PTO built for 8-bolt transmission apertures on Eaton/Fuller, Allison, and Volvo/Mack transmissions, as well as other compatible units. The 885 Series carries an intermittent torque rating up to 500 lb-ft (678 Nm) and delivers 48 HP (36 kW) at 500 RPM and 95 HP (71 kW) at 1,000 RPM. The output shaft is a 1-1/2"-10T spline with a 1410 companion flange, and the unit mounts via an 8-bolt pattern. Continuous operation is supported with a 30% de-rating. Applications include oil field service, bulk transporter trucks, and fire and rescue equipment. A genuine Chelsea part from Pro Gear and Transmission. Call us to confirm proper fit for your application.
Features
Hydraulic PowerShift (PowerShift) shift type for 8-bolt transmission apertures
Intermittent torque rating up to 500 lb-ft (678 Nm); check application pages for actual torque ratings
Output: 48 HP (36 kW) at 500 RPM, 95 HP (71 kW) at 1,000 RPM
1-1/2"-10T spline output shaft with 1410 series companion flange
Rugged cast iron housing with heavy-duty ball bearings on the output shaft
Pressure lubrication available; continuous operation supported with 30% de-rating
Tech Specs
- Intermittent Torque: Up to 500 lb-ft (678 Nm) - check application pages for actual torque ratings
- Shift Type: Hydraulic PowerShift
- Output Power: 56+ HP (51+ kW)
- Transmission Compatibility: Eaton/Fuller, Allison, Volvo/Mack, and other 8-bolt aperture transmissions
- Output Shaft Type: 1-1/2"-10T spline with 1410 series companion flange
- Mounting Type: 8-bolt
- Shaft Power: 48 HP (36 kW) at 500 RPM; 95 HP (71 kW) at 1,000 RPM
- Continuous Operation: Yes, with 30% de-rating
