The Chelsea 890EFFJW-B5XK or 890EFFJWB5XK is a hydraulic PowerShift PTO assembly from the 890 Series, engineered specifically for Allison 3000 MD and 4000 HD Series transmissions. It mounts via a 10-bolt pattern and positions the SAE C output flange at the rear of the transmission, providing clearance between the PTO and the frame rail without requiring a separate extension unit. The main shaft is a single one-piece design that eliminates the input splines found between a standard PTO and an output extension. The wet-spline output lubricates the PTO and pump shaft interface for longer service life in demanding duty cycles. Continuous torque rating reaches 670 ft-lb, with shaft power of 64 HP at 500 RPM and 128 HP at 1,000 RPM. A genuine Chelsea part from Pro Gear and Transmission. Call us to confirm proper fit for your application.
Features
Fits Allison 3000 MD and 4000 HD Series transmissions via 10-bolt mount
Hydraulic PowerShift engagement for hot-shift capability under load
SAE C ("XS") output shaft and outlet flange
Single one-piece main shaft eliminates input splines between PTO and output extension
Wet-spline output extends PTO and pump shaft life in high-demand applications
Continuous torque rating up to 670 ft-lb; shaft power 64 HP at 500 RPM / 128 HP at 1,000 RPM
Tech Specs
- Transmission Fitment: Allison 3000 MD & 4000 HD Series
- Mounting Type: 10-Bolt
- Shift Type: Hydraulic PowerShift
- Output Shaft Type: SAE C ("XS") Output
- Outlet Flange Type: SAE C
- Continuous Torque Rating: 670 lb-ft (check application pages for actual torque ratings)
- Intermittent Torque: 501+ lb-ft
- Shaft Power: 64 HP at 500 RPM / 128 HP at 1,000 RPM
- Output Power: 56+ HP
- Lubricant: Wet Spline
- Product Series: 890
