The Chelsea 890 Series Power Take-Off, part number 890LDFJW-G5XY or 890LDFJWG5XY, is a hydraulic hot-shift PTO engineered specifically for Allison 3000 MD and 4000 HD Series transmissions. It uses a 10-bolt mounting pattern and an SAE C output flange, with a wet-spline output shaft to reduce wear on the PTO and pump shaft in demanding service. The one-piece main shaft eliminates the input splines found in PTO-plus-extension setups, and the rear-mounted clutch lets the housing tuck tightly against the transmission for improved pump clearance. Shaft power output reaches 64 HP at 500 RPM and 128 HP at 1,000 RPM, with a continuous torque rating up to 670 ft-lb. Common applications include aerial trucks, fire and rescue, refuse vehicles, and truck cranes. A genuine Chelsea part available from Pro Gear and Transmission. Call us to confirm proper fit for your application.
Features
Fits Allison 3000 MD and 4000 HD Series transmissions via 10-bolt mount
Hydraulic PowerShift (hot-shift) operation
SAE C output flange with wet-spline output shaft for extended pump shaft life
One-piece main shaft eliminates input splines between PTO and output extension
Rear-mounted clutch positions housing closer to transmission for improved pump clearance
Shaft power: 64 HP at 500 RPM, 128 HP at 1,000 RPM; continuous torque up to 670 ft-lb
Tech Specs
- Transmission Application: Allison 3000 MD and 4000 HD Series
- Product Series: Chelsea 890
- Mounting Type: 10-Bolt
- Shift Type: Hydraulic PowerShift
- Output Shaft Type: SAE C (XS) Output
- Outlet Flange Type: SAE C
- Lubricant: Wet Spline
- Intermittent Torque: 501+ lb-ft
- Continuous Torque: Up to 670 lb-ft (verify actual rating on Chelsea application pages)
- Output Power: 56+ HP (51+ kW)
- Shaft Power: 64 HP (48 kW) at 500 RPM; 128 HP (95 kW) at 1,000 RPM
