The Chelsea 890 Series Power Take-Off Assembly, part number 890LEFJW-K5XK or 890LEFJWK5XK, is a hydraulic hot-shift PTO engineered specifically for Allison 3000 MD and 4000 HD Series transmissions. It mounts with a 10-bolt pattern and delivers an SAE C ("XS") output flange with wet-spline technology to extend PTO and pump shaft life under demanding duty cycles. Continuous torque rating reaches 670 ft-lb, with intermittent torque above 501 ft-lb. Shaft power output is 64 HP at 500 RPM and 128 HP at 1,000 RPM. The one-piece main shaft eliminates input splines between the PTO and output extension, and the extended shaft design moves the pump mounting flange to the rear of the transmission for improved clearance between the pump and frame rail. A genuine Chelsea part from Pro Gear and Transmission. Call us to confirm proper fit for your application.
Features
Fits Allison 3000 MD and 4000 HD Series transmissions (FJ input gear designator)
Hydraulic PowerShift (hot-shift) operation
10-bolt mounting with SAE C ("XS") output flange
Wet-spline output extends PTO and pump shaft life
Extended shaft relocates pump flange to rear of transmission for improved pump clearance
Continuous torque rating up to 670 ft-lb; intermittent torque 501+ ft-lb
Tech Specs
- Transmission Application: Allison 3000 MD and 4000 HD Series
- Product Series: 890
- Mounting Type: 10-Bolt
- Shift Type: Hydraulic PowerShift (hot-shift)
- Output Shaft Type: SAE C ("XS") Wet-Spline Output
- Outlet Flange Type: SAE C
- Continuous Torque: 670 ft-lb (check application pages for actual torque ratings)
- Intermittent Torque: 501+ ft-lb
- Shaft Power: 64 HP at 500 RPM / 128 HP at 1,000 RPM
- Output Power: 56+ HP
