The Dana Spicer D463 axle housing, part number 321096, is built to D463 axle specifications with an overall length of 2078.00 mm and a wall thickness of 14.00 mm. The housing features an induction-hardened Series R spindle and a box section measuring 133 x 117 mm. Bowl offset is 66.00 mm. The hub mounting face uses a 15+1 hole pattern with hole sizes of .656 and .812 inches, a bolt circle diameter of 209.50 mm, and a pilot diameter of 171.45 mm. Index angle is 22.50 degrees, measured counter-clockwise from 12:00. Also listed under the Spicer brand as EH321096. Call us to confirm proper fit for your axle configuration.
Features
Overall length: 2078.00 mm
Wall thickness: 14.00 mm
Induction-hardened Series R spindle
Box section: 133 x 117 mm
Bolt circle diameter: 209.50 mm, pilot diameter: 171.45 mm
15+1 hole pattern; hole sizes .656 and .812 in.; index angle 22.50 deg. CCW from 12:00
Tech Specs
- Overall Length: 2078.00 mm
- Wall Thickness: 14.00 mm
- Box Section: 133 x 117 mm
- Bowl Offset: 66.00 mm
- Spindle Series: R
- Induction Hardened Spindle: Yes
- Rolled Over: No
- Pilot Diameter: 171.45 mm
- Bolt Circle Diameter: 209.50 mm
- Hole Pattern: 15+1
- Hole Size: .656 + .812 in.
- Index Angle (CCW from 12:00): 22.50 deg.
