Dana Driveshaft - driveline part P/N: 250DS55003F-80M or 250DS55003F80M, we offer original, genuine parts straight from the manufacturer! Call today.
Tech Specs
- Series SPL250
- Shaft Material Steel
- Invoice Drive Shaft
- Tube Size (MM) 130.0000 x 5.0000
- Max Slip (MM) 110.0000
- Tube Size (IN) 5.1181 x .1968
- Max Slip (IN) 4.3307
- Tube Length (MM) 80.0000
- Mid Slip (MM) 55.0000
- Tube Length (IN) 3.1496
- Mid Slip (IN) 2.1654
- CL Yoke To CL Yoke (MM) - COLL 461.0000
- CL Yoke To CL Yoke (IN) - COLL 18.1496
- 1/2 Max Slip (MM) 55.0000
- 1/2 Max Slip (IN) 2.1654
- VMRS 024000000
- Phased (Yes/No) No
- Phased - Degrees 0
- Joint Angle 25
- CL Yoke To Flange Face (MM)-COLL 25
- CL Yoke To Flange Face (IN)-INST Welded
- No. of Universal Joint Included Yes
- U-Joint Style 2
- CL Yoke To CL Yoke (MM)-INST ST
- CL Yoke To End Of Spline Sleeve (MM)-COLL 516.0000
- CL Yoke To End Of Spline Sleeve (IN)-COLL 20.3150
- Slip Assembly No
- Slip Yoke C to End (MM) No
