The Dana Spicer 170IA55010F-240M or 170IA55010F240M is an SPL170-series Interaxle XL Shaft designed for light axle driveline applications. The steel tube measures 4.5944 inches in diameter with a 0.1799-inch wall and a tube length of 6.6929 inches (170 mm). Center-line yoke to center-line yoke collapsed length is 24.6614 inches (626.4 mm), with center-line yoke to end of spline sleeve reaching 27.6142 inches (701.4 mm) collapsed. Maximum slip is 5.9055 inches (150 mm); mid-slip is 2.9528 inches (75 mm). The shaft carries a Style 2 U-joint, runs at a 45-degree joint angle, and is not phased. The flange end is welded. One universal joint is included. Call us to confirm proper fit for your application.
Features
SPL170 series Interaxle XL Shaft, part number 170IA55010F-240M or 170IA55010F240M
Steel tube: 4.5944 in. diameter x 0.1799 in. wall (116.7 mm x 4.57 mm)
Tube length: 6.6929 in. (170 mm)
Center-line yoke to center-line yoke collapsed: 24.6614 in. (626.4 mm)
Center-line yoke to end of spline sleeve collapsed: 27.6142 in. (701.4 mm)
Style 2 U-joint included; joint angle 45 degrees; non-phased; welded flange end
Tech Specs
- Series SPL170
- Shaft Material Steel
- Type Interaxle XL Drive Shaft
- Tube Size (in.) 4.5944 dia. x 0.1799 wall
- Tube Size (mm) 116.70 x 4.57
- Tube Length (in.) 6.6929
- Tube Length (mm) 170.00
- Max Slip (in.) 5.9055
- Max Slip (mm) 150.00
- Mid Slip (in.) 2.9528
- Mid Slip (mm) 75.00
- 1/2 Max Slip (in.) 2.9528
- 1/2 Max Slip (mm) 75.00
- CL Yoke To CL Yoke - Collapsed (in.) 24.6614
- CL Yoke To CL Yoke - Collapsed (mm) 626.40
- CL Yoke To End Of Spline Sleeve - Collapsed (in.) 27.6142
- CL Yoke To End Of Spline Sleeve - Collapsed (mm) 701.40
- CL Yoke To Flange Face - Collapsed (mm) 45
- Flange End Welded
- U-Joint Style 2
- Universal Joint Included Yes
- Joint Angle 45 degrees
- Phased No
- Phased Degrees 0
- Slip Assembly No
- VMRS Code 024000000
