The Dana Spicer 134316 (also listed as EH134316) is a differential bearing cage and cup assembly designed for on-highway axle applications. This assembly serves as the differential pin bearing retainer, combining the bearing cage and cup in a single unit for direct installation. The 6-hole bolt pattern features a 184.15 mm bolt circle with hole diameters ranging from 14.94 to 15.35 mm, giving technicians the clearance needed for proper hardware seating. Cross-references include 129767, 134316ETN, 2719-134316, and 2719134316. Call us to confirm proper fit for your specific axle configuration.
Features
Differential bearing cage and cup assembly (diff pin bearing retainer)
6-bolt mounting pattern
Bolt circle: 184.15 mm
Hole diameter: 14.94-15.35 mm
Cross-references: 129767, 134316ETN, 2719-134316, 2719134316
Designed for on-highway axle applications
Tech Specs
- Bolt Circle: 184.15 mm
- Hole Diameter: 14.94-15.35 mm
- Number of Holes: 6
- Part Number: 134316 or EH134316
