Genuine Dana Spicer Comp Flange - driveline part P/N: 6.5-1-2361X or 6512361X, Genuine parts, premium service! Repair your vehicle with authentic parts! We bring Dana's genuine parts to the world. Expert support always available!
Tech Specs
- Series 1810
- Invoice COMP. FLANGE ASSY
- Major Diameter (D) In. 2.750
- Spline Count 10
- Involute Spline N
- Pilot Diameter (C) In. 7.750 - FEMALE
- Bolt Circle Dia.(B) In.(FL YK) 7.25
- Bolt Hole Diameter In (FL YK) 0.438 - DRILLED
- Number Of Holes (FL YK) 12
- Ground Hub Diameter In. 3.750
- Length Thru Hole (F) In. 3.000
- Flange Face To End Of Hub (G) 4.062
- Companion Flange Assembly Y
- Material Steel
