Dana Spicer driveshaft part number 922438-1572M or 9224381572M is a 1350 series aluminum tube driveshaft built for heavy-duty driveline applications. The aluminum tube measures 127.6 x 1.89mm, and the collapsed center-line yoke-to-yoke length is 1572.0mm. Center-line yoke-to-bearing dimension is 61.8898mm. Flange face-to-flange face center-line measures 19.5mm, and the yoke-to-flange face center-line is 26.5mm. This shaft carries no outboard spline. Confirm this part fits your specific application before ordering, or call us and we will help verify the correct fitment for your truck.
Features
Dana Spicer 1350 series driveshaft
Aluminum tube construction, 127.6 x 1.89mm tube size
Collapsed center-line yoke-to-yoke length: 1572.0mm
Center-line yoke-to-bearing dimension: 61.8898mm
Flange face-to-flange face center-line: 19.5mm
Yoke-to-flange face center-line: 26.5mm
Tech Specs
- Series 1350
- Invoice Drive Shaft
- Shaft Material Aluminum
- Tube Size (MM) 127.6 x 1.89
- Max Slip (MM) 5.02 x .074
- Cl Yoke To Cl Yoke(MM) - COLL. 1572.0000
- CL (Yoke To Bearing) (MM) 61.8898
- VMRS 024000000
- Outboard Spline Quantity No
- Grade Type 0
- CL(Flange Face To Flange Face) 19.5
- CL (Yoke To Flange Face) 26.5
