The Dana Spicer 47858 is a Round Hi-Shear spindle nut engineered for Series 80 and S111 axle applications. It carries a 2.5-12 thread size and a 4.169-inch (105.89 mm) hex, with a height of 1.060 inch (27.00 mm) and a thickness of 26.92 mm. Flange diameter measures 105.89 mm. The nut is self-locking and includes the outer wheel bearing nut. Manufactured from steel and sold individually, it corresponds to OE casting number F81A-1A124-AA. This is a genuine Dana Spicer part available from Pro Gear and Transmission. Call us to confirm proper fit for your axle configuration.
Features
Series 80 and S111 axle application
Round Hi-Shear type, self-locking design
2.5-12 thread size
4.169 in. (105.89 mm) hex size
Height: 1.060 in. (27.00 mm); thickness: 26.92 mm
OE number F81A-1A124-AA; outer wheel bearing nut included
Tech Specs
- Series: 80, S111
- Type: Round Hi-Shear
- Thread Size: 2.5-12
- Self-Locking: Yes
- Hex Size: 4.169 in. (105.89 mm)
- Height: 1.060 in. (27.00 mm)
- Thickness: 26.92 mm
- Flange Diameter: 105.89 mm
- Material: Steel
- Outer Wheel Bearing Nut Included: Yes
- Hardware Included: No
- Quantity: 1
- OE Part Number: F81A-1A124-AA
