The Dana Spicer 46901 is a front outer axle shaft engineered for the Dana 60 axle. It features a 33-spline count and a 7.060-inch outer stub length, and it is positioned at the front outer location of a non-ABS axle setup. The shaft does not include a universal joint, though the applicable U-joint series for this application is the 1480. With 10 axle cover bolt holes on the Dana 60 housing, this steel shaft is a direct fit for the application. Call us to confirm proper fit for your specific vehicle before ordering.
Features
Dana 60 front outer axle shaft
33-spline outer stub
7.060-inch outer stub length
Non-ABS application
1480 series U-joint compatible (U-joint not included)
10-bolt axle cover configuration
Steel construction
Tech Specs
- Axle Model DANA 60
- Invoice Shaft
- Material Steel
- Axle Cover Bolt Hole Qty 10
- ABS/Non-ABS Non-ABS
- Location Front Outer
- Axle Type Outer
- Length (IN) 7.060
- Spline Count 33
- Outer Stub Length (In) 7.060
- Outer Stub Spline Count 33
- Includes Universal Joint N
- Universal Joint Series 1480
- Includes Tone N
