The Dana Spicer 673240 right angle connection is a 360 brass alloy fitting used in Central Tire Inflation System (CTIS) plumbing. It features a .375-32 UNEF-2B outlet thread and an outlet inside diameter of 8.01 mm, or .315 in. The hex head measures 22.3 mm across with a hex head length of 31.0 mm, or 1.22 in. The right angle design routes air lines in tight wheel-end and chassis locations where a straight fitting will not clear. Sold by Pro Gear and Transmission. Call us to confirm proper fit for your application.
Features
360 brass alloy construction
Right angle design for tight routing in CTIS air lines
Outlet thread: .375-32 UNEF-2B
Outlet inside diameter: 8.01 mm / .315 in.
Hex head dimension: 22.3 mm
Hex head length: 31.0 mm / 1.22 in.
Tech Specs
- Material 360 Brass Alloy
- Hex Head Dimension 22.3
- Hex Head Length 31.0 [1.22]
- Outlet Inside Diameter 8.01 [.315]
- Outlet Thread .375-32 UNEF-2B
