Dana Spicer part number 2005116-5 or 20051165 is a ring and pinion set engineered for the Dana 44 semi-floating rear axle. The 4.10 gear ratio is achieved through a 41-tooth ring gear paired with a 10-tooth pinion. The ring gear measures 8.900 inches in diameter and mounts with 10 bolts on a .437-20 thread. Pinion shaft diameter is 1.626 inches with 24 splines. Ring gear rotation is standard. The set includes the ring gear, pinion gear, pinion nut, and installation kit. Shims are not included. Call us to confirm proper fit for your application.
Features
Dana 44 semi-floating rear axle application
4.10 gear ratio: 41-tooth ring gear, 10-tooth pinion
8.900 in. ring gear diameter, 10-bolt mounting (.437-20 thread)
1.626 in. pinion shaft diameter with 24-spline count
Includes ring gear, pinion gear, pinion nut, and installation kit
Standard ring gear rotation, rear axle location
Tech Specs
- Axle Model: Dana 44
- Axle Type: Semi Floating
- On Vehicle Location: Rear
- Gear Ratio: 4.10
- Ring Teeth Count: 41
- Pinion Gear Tooth Quantity: 10
- Ring Gear Diameter: 8.900 in.
- Ring Gear Bolt Quantity: 10
- Ring Gear Bolt Thread: .437-20 in.
- Cover Bolt Quantity: 10
- Pinion Shaft Diameter: 1.626 in.
- Pinion Spline Count: 24
- Ring Gear Rotation: Standard
- Carrier Breaks: None
- Installation Kit Included: Yes
- Ring Gear Included: Yes
- Pinion Gear Included: Yes
- Pinion Nut Included: Yes
- Shims Included: No
