The Dana Spicer 100CS54001-755M or 100CS54001755M is an SPL100 series coupling shaft built from steel tubing measuring 4.00 inches in diameter with a .134-inch wall (101.60 x 3.40 mm). Tube length is 755.0 mm (29.72 in.), and the collapsed centerline yoke-to-yoke dimension is 989.4 mm (38.95 in.). Centerline yoke to centerline bearing measures 874.6 mm (34.43 in.). The joint angle rating is 25 degrees. The flange face installation is welded. This shaft is non-phased, includes one universal joint (Style 1), and is listed as SR/HR for the installed centerline yoke-to-yoke configuration. No slip assembly. Call us to confirm proper fit for your application.
Features
SPL100 series coupling shaft, part number 100CS54001-755M or 100CS54001755M
Steel tube: 4.00 in. diameter x .134 in. wall (101.60 x 3.40 mm)
Tube length: 755.0 mm (29.72 in.)
Collapsed centerline yoke-to-yoke: 989.4 mm (38.95 in.)
Joint angle: 25 degrees; flange face installation is welded
Includes one U-joint (Style 1); non-phased; no slip assembly
Tech Specs
- Series SPL100
- Shaft Material Steel
- Type Coupling Shaft
- Tube Size (in.) 4.00 x .134
- Tube Size (mm) 101.60 x 3.40
- Tube Length (in.) 29.72
- Tube Length (mm) 755.0
- CL Yoke to CL Yoke - Collapsed (in.) 38.95
- CL Yoke to CL Yoke - Collapsed (mm) 989.4
- CL Yoke to CL Bearing (in.) 34.43
- CL Yoke to CL Bearing (mm) 874.6
- Joint Angle 25 degrees
- Flange Face Installation Welded
- U-Joint Included Yes
- U-Joint Style 1
- Installed CL Yoke to CL Yoke Config SR / HR
- Phased No
- Slip Assembly No
- VMRS Code 024002062
