Genuine Dana Spicer Shaft Assembly for light axle application P/N: 84377-1 or 843771, Genuine parts, direct from Dana Spicer. Your equipment deserves the best! Experience global delivery of Dana's genuine parts. We're here to help anytime!
Tech Specs
- Axle Model DANA 44
- Material Steel
- Invoice Shaft Assy
- Axle Cover Bolt Hole Qty 10
- ABS/Non-ABS Non-ABS
- Location RH
- Length (IN) 29.710
- Axle Length (In) 29.710
- Spline Count 30 Inboard
- Axle Spline Count 30 Inboard
- Bolt Pattern 5 X 4.50
- Wheel Stud Hole Diameter (In) 0.607
- Brake Pilot Diameter (In) 2.842
- Bearing Pilot Diameter (In) 1.535
- Cover Bolt Quantity 10
- Includes Tone Y
- Axle Length (Mm) 754.634
- ABS Sensor Ring Included No
- ABS Sensor Ring Installed N
- Axle Shaft Included Y
- Axle Type Complete Assembly
- Bearing Included Y
- Full-Floating Or Semi-Floating Semi-Floating
- Inner Axle Included Y
- Number Of Wheel Lugs 5
- Outer Axle Included Y
- Quantity 1
- Retainer Ring Included Y
- Seal Included Y
- Seal Kit Included N
- U-Joint Included N
- Wheel Bearing Included Y
- Wheel Bolt Prep Kit Included N
- Wheel Nuts Included N
- Wheel Studs Included Y
- Length (MM) 754.634
