The Eaton Advantage Self-Adjust clutch, part number 309708-32 or 30970832, is a heavy-duty manual transmission clutch rated at 2,250 ft-lb of torque capacity. The 15.5-inch assembly uses a 2.00"-14 input shaft, ceramic friction facing across 6 friction pads and 2 discs, and includes hydraulic linkage compatibility. Seven damper springs are used in the damper assembly; the unit does not include a pre-damper. Eaton rates this clutch in their "Best" portfolio tier for heavy-duty vehicle classifications. Cross-reference numbers include 209701-32 and NMU701-157-8. Call us to confirm proper fit for your application.
Shipped on pallet.
Features
15.5-inch clutch size rated at 2,250 ft-lb torque capacity
Ceramic friction facing with 6 friction pads across 2 discs
2.00"-14 input shaft size
Hydraulic linkage compatible
7 damper springs; no pre-damper
Eaton "Best" portfolio rating for heavy-duty applications
Tech Specs
- Input Shaft Size: 2.00"-14
- Clutch Size: 15.5 in.
- Torque Rating: 2,250 ft-lb
- Number of Discs: 2
- Friction Pad Count: 6
- Facing Material: Ceramic
- Damper Spring Count: 7
- Pre-Damper: No
- Hydraulic Linkage: Yes
- Transmission Type: Manual
- Vehicle Classification: Heavy Duty
- Portfolio Rating: Best
