The Eaton Bezares PT4110XJN243DA or 4110XJN243DA is a heavy-duty, low-profile power take-off built for very heavy duty applications. It mounts in the bottom-left position on Mack DIN transmissions using an 8-bolt pattern and engages via pneumatic (air) shifting. The unit uses a two-gear design with multiple available transmission ratios: 70% (C), 86% (E), and 105% (J). Air connection is threaded 1/4" BSP. Additional features include a backlash check plug, indicator switch, and drive flange. This PTO is also available in mounting positions 1 and 3. Call Pro Gear and Transmission to confirm the correct ratio and mounting position for your specific application.
Features
8-bolt Mack DIN mounting pattern, bottom-left position (also available in positions 1 and 3)
Pneumatic (air) shift engagement; air connection threaded 1/4" BSP
Two-gear, low-profile design rated for very heavy duty service
Available internal ratios: 70% (C), 86% (E), and 105% (J)
Includes backlash check plug, indicator switch, and drive flange
Intermittent service torque up to 470 lb-ft; continuous service up to 340 lb-ft (at 70% and 86% ratios)
Tech Specs
- Mounting position: Bottom left
- Also available in: Position 1, Position 3
- Air connection thread: 1/4" BSP
- Gear configuration: Two-gear, low-profile
- Available internal ratios: 70% (C), 86% (E), 105% (J)
- Features: Rotation note, backlash check plug, indicator switch, drive flange
Additional Information
| Engine to PTO ratio | ||||||
|---|---|---|---|---|---|---|
| INTERNAL RATIO | INTERMITTENT SERVICE | CONTINUOUS SERVICE | ||||
|
Torque
(Lb. FT) |
Power (HP) |
Torque
(Lb. FT) |
Power (HP) | |||
| At 500 r.p.m. | At 1000 r.p.m. | At 500 r.p.m. | At 1000 r.p.m. | |||
| 70%(C) | 470 | 45 | 90 | 340 | 33 | 65 |
| 86%(E) | 470 | 45 | 90 | 340 | 33 | 65 |
| 105%(J) | 400 | 39 | 77 | 300 | 29 | 58 |
