Eaton Bezares PTO 8 Bolt Hd P/N: PT4110XEN751SE or 4110XEN751SE

Stock photo not actual item

PT4110XEN751SE Eaton Bezares 8-Bolt Heavy Duty PTO or 4110XEN751SE

Eaton Bezares

PTO 8 Bolt Hd

Listing Price: $4,531.77
Sale Price: $2,492.47

This item qualifies for FREE shipping on orders over $295 and under 70 lbs

(No reviews yet) Write a Review
Product Code:
BEZPT4110XEN751SE
Condition:
New
Availability:
Usually Ships in 3 to 5 Business Days
Adding to cart… The item has been added
The Eaton Bezares PT4110XEN751SE or 4110XEN751SE is an 8-bolt heavy-duty power take-off built for very heavy-duty truck applications. Its low-profile two-gear design offers multiple internal transmission ratios, including 70% (C), 86% (E), and 105% (J) engine-to-PTO ratios. Intermittent-service torque capacity reaches 470 lb-ft at 500 RPM with 90 HP at 1,000 RPM for the 70% and 86% ratio versions. The 105% ratio version is rated at 400 lb-ft intermittent at 500 RPM and 77 HP at 1,000 RPM. Pneumatic shifting via a 1/4" BSP air connection keeps engagement clean and reliable. The unit mounts in the bottom-left position, with a backlash check plug, indicator switch, and drive flange. Also available in mounting positions 1 and 3. Call us to confirm the correct ratio and mounting position for your application.

Features

8-bolt heavy-duty mounting for demanding truck auxiliary power applications
Low-profile two-gear design with selectable internal ratios: 70% (C), 86% (E), and 105% (J)
Intermittent torque capacity up to 470 lb-ft at 500 RPM (70% and 86% ratio versions)
Pneumatic shifting with 1/4" BSP air connection thread
Bottom-left mounting position standard; also available in positions 1 and 3
Includes backlash check plug, indicator switch, and drive flange

Tech Specs

  • Mounting position: Bottom left
  • Air connection thread: 1/4" BSP
  • Shift type: Pneumatic
  • Internal ratio options: 70% (C), 86% (E), 105% (J)
  • Intermittent torque at 500 RPM (70%/86%): 470 lb-ft
  • Intermittent power at 1,000 RPM (70%/86%): 90 HP
  • Continuous torque at 500 RPM (70%/86%): 340 lb-ft
  • Continuous power at 1,000 RPM (70%/86%): 65 HP
  • Intermittent torque at 500 RPM (105%): 400 lb-ft
  • Intermittent power at 1,000 RPM (105%): 77 HP
  • Continuous torque at 500 RPM (105%): 300 lb-ft
  • Continuous power at 1,000 RPM (105%): 58 HP
  • Note C: Backlash check plug
  • Note D: Indicator switch
  • Note E: Drive flange
  • Cross reference: 4110XEN751SE

Additional Information

Engine to PTO ratio
INTERNAL RATIO INTERMITTENT SERVICE CONTINUOUS SERVICE
Torque
(Lb. FT) 		Power (HP) Torque
(Lb. FT) 		Power (HP)
At 500 r.p.m. At 1000 r.p.m. At 500 r.p.m. At 1000 r.p.m.
70%(C) 470 45 90 340 33 65
86%(E) 470 45 90 340 33 65
105%(J) 400 39 77 300 29 58
!
