The Eaton Fuller K-1996 or K1996 is a Basic Overhaul Kit covering RTX and RTXF series 9-speed transmissions, including models RTX-11709A, RTX-11709B, RTX-11709H, RTX-11710B, RTX-12709A, RTX-12709B, RTX-12709H, RTX-12710B, RTXF-11709H, RTXF-11710B, RTXF-11710C, RTXF-12709H, RTXF-12710B, and RTXF-12710C. The kit is built around a full complement of internal components: multiple snap rings (part numbers 14317, 14750, 16763, 16980), a set of position-finder springs and standard springs, an assortment of bearings including a reverse gear idler shaft bearing and a ball bearing assembly, a sliding clutch, an input shaft assembly, an oil seal with slinger, a gasket kit, an O-ring kit, a shim kit, sealant, and instruction letters. A genuine Eaton Fuller kit, sold by Pro Gear and Transmission. Call us to confirm proper fit for your application.
14317 - Snap Ring x2
14750 - Snap Ring x1
14897 - Spring x3
15918 - Spring, Position Finder x3
16763 - Snap Ring x2
16980 - Snap Ring x1
21355-BOX - Bearing x1
4302074-BOX - Bearing x4
4306030 - Ball Bearing x2
4306648 - Sliding Clutch x1
4308403 - Reverse Gear Idler Shaft Bearing x2
4308452 - Bearing x2
5566507-BOX - Bearing x1
71205 - Sealant x1
81504 - Ball Bearing x1
83001 - Collet x4
84002 - Connector, Straight x1
85002 - Connector, Elbow x1
K-1450 - O-Ring Kit x1
K-2061 - Gasket Kit x1
K-2262 - Oil Seal with Slinger x1
K-2805 - Shim Kit x1
L-1680 - Instruction Letter x1
L-3887 - Instruction Letter x1
L-3987 - Instruction Letter x1
S-1659 - Input Shaft Assembly x1
Features
Fits 14 RTX and RTXF series transmission models including RTX-11709A through RTXF-12710C
Includes snap rings: part numbers 14317 (x2), 14750 (x1), 16763 (x2), and 16980 (x1)
Bearing set covers multiple positions: standard bearings, ball bearings, and reverse gear idler shaft bearings
Includes sliding clutch (4306648), input shaft assembly (S-1659), and oil seal with slinger (K-2262)
Gasket kit (K-2061), O-ring kit (K-1450), shim kit (K-2805), and sealant (71205) included
Instruction letters included in kit for installation reference
Additional Information
Kit Bill of Materials - Eaton Fuller K-1996 Basic Overhaul Kit:14317 - Snap Ring x2
14750 - Snap Ring x1
14897 - Spring x3
15918 - Spring, Position Finder x3
16763 - Snap Ring x2
16980 - Snap Ring x1
21355-BOX - Bearing x1
4302074-BOX - Bearing x4
4306030 - Ball Bearing x2
4306648 - Sliding Clutch x1
4308403 - Reverse Gear Idler Shaft Bearing x2
4308452 - Bearing x2
5566507-BOX - Bearing x1
71205 - Sealant x1
81504 - Ball Bearing x1
83001 - Collet x4
84002 - Connector, Straight x1
85002 - Connector, Elbow x1
K-1450 - O-Ring Kit x1
K-2061 - Gasket Kit x1
K-2262 - Oil Seal with Slinger x1
K-2805 - Shim Kit x1
L-1680 - Instruction Letter x1
L-3887 - Instruction Letter x1
L-3987 - Instruction Letter x1
S-1659 - Input Shaft Assembly x1
